Small Block Ford Fabricated Aluminum Valve Covers

SAME DAY SHIPPING! Order within the next 11 hours 29 minutes and receive same day shipping

Free Shipping Free Shipping
Specs
Material Type:
Aluminum
Sold in Quantity:
Pair
Baffled:
No
Garage Sale:
No
Overall Height:
3.50
Small Block Ford Fabricated Aluminum Valve Covers
Small Block Ford Fabricated Aluminum Valve Covers
Small Block Ford Fabricated Aluminum Valve Covers

Click image to enlarge

Please NOTE the following about this product:

  • This item is sold as a pair.

Details

Reviews

Q & A

What's in the Box

Whether you're going for the hardcore race look or just trying to save weight, these fabricated aluminum valve covers are for you! These fully welded sheet aluminum covers feature a 1/8" thick flange for a great seal. Can be painted, polished, or left in bare aluminum finish. Bolts and washers included for mounting with valve cover.

Fits 1962-1985 Small Block Ford 260-289-302-351W & 5.0L

Specs

  • Overall Height:  3-1/2"
  • Included Bolt Length:  4-1/2"
  • These valve covers do not contain baffles
  • Gaskets NOT included

Customer Reviews

Rated 5 out of 5 by 1 reviewers.
RATING BREAKDOWN
1 reviews
5 Stars
1
4 Stars
0
3 Stars
0
2 Stars
0
1 Star
0
RECOMMEND THIS PRODUCT:

SATXCarGuy
Verified Purchaser
San Antonio, TX, USA

Beautiful Valve Covers

February 03, 2013
Great valve covers, welds are gorgeous. The only issue I had with them is cutting them for a breather system, which I honestly wouldn't have done expect that oil fill on SBFs is most easily accomplished through the valve cover.
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Page 1 of 1

Product Q&A

1 questions : 1 answers

1 answers

Dimensions Hello, can you please provide heights of covers from head to each portion of top bend of valve cover? Thank you. Pictures provided for referencing of heights.

flyboygeo
TN
February 13, 2014

Dimensions Hello, can you please provide heights of covers from head to each portion of top bend of valve cover? Thank you. Pictures provided for referencing of heights.

Answers

February 14, 2014
EricM
These valve covers are 2 3/4" tall at the inner and outer edge and 3 1/2" tall at the center.
Page 1 of 1
