Professional Products 10211 Polished Aluminum Inline Fuel Filter

Specs
Material Type:
Aluminum
Overall Length:
2.40
Sold in Quantity:
Each
Finish:
Polished
Outside Diameter:
1.50
Thread Pitch:
3/8" NPT
Flow Rating:
160 GPH at 7 PSI
MFG. Part #:
10211
Filter Element Type:
Stainless Steel Mesh
Notes
Filters down to 35 microns, screen can be cleaned in solvent and re-used.
Professional Products 10211 Polished Aluminum Inline Fuel Filter

Click image to enlarge

Details

Reviews

Q & A

What's in the Box

Highly polished aluminum filter complete with reusable 35 micron stainless steel mesh filter element. Intended for carbureted systems with 8 PSI max pressure. Filter elements can be cleaned in solvent and reused.
  • Designed for low pressure, carbureted systems
  • Flows 160 gallons per hour at 7 psi
  • 3/8" NPT female threads

Customer Reviews

Rated 4.7 out of 5 by 3 reviewers.
RATING BREAKDOWN
3 reviews
5 Stars
2
4 Stars
1
3 Stars
0
2 Stars
0
1 Star
0
RECOMMEND THIS PRODUCT:

Andy
New England
Product Rating

fuel leak

November 16, 2012
leaked when I installed it. Turns out the problem was with one of the aluminum fittings that was recommended to adapt to AN-6 hose. I used a pipe bushing 3/8 to 1/4 and a steel 1/4 pipe to AN-6 fitting and this corrected the leak.
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

David Hancock
Verified Purchaser
Omaha, NE
Product Rating

Great!

November 04, 2011
Looks good, runs good!
Pros:
  • Lightweight
  • Easy To Install
  • Durable
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

J. D.
Springfield MO
Product Rating

Great Product

June 18, 2010
It matches the chrome and stainless parts on my car great and could mount anywhere.
Pros:
  • Matching finish
  • Compact Size
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Page 1 of 1

Product Q&A

1 questions : 1 answers

Can this filter be used as a pre-filter for a diesel engine? The problem I have is that my fuel filter plugs frequently and I would like to prefilter the fuel before it gets to the standard fuel filter. It is a 4 cylinder diesel so the fuel flow should no

1 answers
Denny
August 02, 2011

Can this filter be used as a pre-filter for a diesel engine? The problem I have is that my fuel filter plugs frequently and I would like to prefilter the fuel before it gets to the standard fuel filter. It is a 4 cylinder diesel so the fuel flow should no

Answers

August 03, 2011
John
This filter is mainly designed for carbureted systems but if used for other applications you will need to recognize the pressure limitations of 8 psi. If running before the pump on a suction type line would not be a problem but on the pressure side exceeding the 8 psi it is not recommended. In higher pressure applications you may want to consider 91002335 with a reusable stainless filter element.
