Hyperco 10231 Chrysler Composite Leaf Spring, 200 Lb. Rate

Specs
Sold in Quantity:
Each
Number of Leafs:
1
Finish:
Natural
Material Type:
Composite
Leaf Spring Eye Type:
Berlin Eye
Spring Location:
Rear
MFG. Part #:
10231
Length Eye to Eye:
53.88
True Arch:
4.50
Front Eye I.D.:
0.625
Rear Eye I.D.:
0.5
Spring Rate:
200
Hyperco 10231 Chrysler Composite Leaf Spring, 200 Lb. Rate

Click image to enlarge

Details

Reviews (0)

Q & A (0)

What's in the Box

Info

Hyperco Composite Leaf Springs are significantly lighter than steel, retain their design arch, and provide more side bite off the corner. The Hyperco CLS is truly a cost effective, high performance alternative to steel. It allows teams running leaf springs to be consistent night after night without having to constantly measure, monitor and change their springs for loss of arch / sagging. The initial cost is a value based on the incredible service life. Leave the steel on the street, hook up with the Hyperco CLS performance advantage.

  • On average 70% lighter than steel
  • No sagging or chassis inconsistency
  • More durable = greater value
  • Quicker off the corner compared to steel springs

Composite Spring Dimensions (GIF)

Item Details

Front Bolt: 0.625"
Rear Bolt: 0.5"
Arch: 4.5"
Rate: 200#

Notes

  1. U-bolts should never come in contact with the composite portion of the leaf spring. Hyperco recommends a heavy gauge rubber or plastic hose be fitted over the U-bolts to ensure that there is no metal to composite contact.
  2. U-bolts should be tightened evenly to a torque value of 80 to 100 ft. lbs., or until the center mounting plate yields/deflects. The torque value should be checked on a regular basis to ensure adequate and consistent clamping force.
  3. The mounting pad must extend a minimum of ¼" past the steel mounting plate.
  4. Additional protection for the composite leaf can be obtained by wrapping all exposed surfaces with high quality duct tape.
  5. When installing springs it is important to check the alignment. The inner sleeves must not bind inside the spring bushings on both the front and rear mounting brackets.
