Book - How to Build and Modify LS-Series Engines

SAME DAY SHIPPING! Most orders ship within 24 hours.

Book - How to Build and Modify LS-Series Engines
Book - How to Build and Modify LS-Series Engines

Click image to enlarge

Speeday Motors Logo
X
Book - How to Build and Modify LS-Series Engines

Details

Reviews

Q & A

What's in the Box

For those who want to build or modify their LS engine, this book provides the most detailed and extensive instructions ever offered. Whatever your performance goals might be, How to Build and Modify GM LS-Series Engines shows you what modifications are needed and how to make them. Premier LS engine technician Joseph Potak addresses every question that might come up, covering topics including crankshafts and piston assemblies, cylinder heads, camshafts, valvetrain, block modifications, intake manifolds, fuel system, header selection, and setting up ring and bearing clearances for particular uses. In short, this book is the ultimate resource for building the ultimate LSX engine.

By Joseph Potak. Paperback, 176 pages with 300 color photos. 8.25" x 10.625"



You may also be interested in:

Book - How to Build High Performance Chevy LS1-LS6 V8s
                        The LS1/LS6 family of engines are quickly becoming the engine of choice for high performance street and race applications. Learn what it takes to build these engines right in this engine building book. 600 photos. 160 pages.

Edelbrock 7118 Performer RPM LS1 Manifold & Timing Control Module


Some people would prefer to have a good old 4 barrel carburetor instead of fuel injection. This Edlebrok LS1 4 barrel Intake allows you to do just that and includes the MSD box and harness to run the ignition system.

This powerful new manifold is designed for the popular Chevrolet LS1 (5.7L) small-block V8 originally used in 1997 and later Corvettes and 1998-02 Camaros and Firebirds. It also fits the Corvette LS6 engine and any other Gen III engine including the LM7 (5.3L), LR4 (4.8L), and LQ4 (6.0L). It allows the use of a carburetor on these originally computer-controlled engines, offering maximum power and a broad torque curve from 1500 to 6500 rpm. This manifold made 410 hp and 418 ft/lbs. of torque in dyno tests. The Performer RPM LS1 includes a wiring harness and unique electronic Timing Control Module made by MSD® which works with OE sensors to fire the coil-on-plug ignition system and offers a choice of six timing curves. A special throttle and trans bracket that works with 700R-4, 200R-4 and Turbo 350 transmissions is included, making the LS1 engine an easy retro-fit into any muscle car, street rod or marine application.

325-7118 Instructions (PDF)


Lokar ED-5008 1997-04 GM LS1 Engine Dipstick
                        Get rid of that ugly OEM dipstick and replace it with this clean Lokar piece. It's the best dipstick you can buy for your 97 and up LS1.

F-Body LS1 High Mount Alternator Relocation Bracket


If you want to get rid of your power steering and move the alternator up to the driver side head, this is the bracket for you. It allows you to retain your original F-body alternator, balancer, A/C bracket and compressor.

Includes a billet aluminum bracket, belt and hardware.

Lokar TCB-40LS1 1998-99 LS1 Throttle Cable Bracket, Single
                        Clean up your LS1 intake manifold with this billet aluminum cable bracket. Available with a single stud for throttle only or a double stud to add cruise control or kickdown cable. Designed to work with part #491-1000LS1.

Lokar TCB-40LS13 2000-04 LS1 Throttle Cable Bracket, Single
                        Clean up your LS1 intake manifold with this billet aluminum cable bracket. Available with a single stud for throttle only or a double stud to add cruise control or kickdown cable. Designed to work with part #491-1000LS1.

Lokar TCB-40LS12 1998-99 LS1 Throttle Cable Bracket, Double
                        Clean up your LS1 intake manifold with this billet aluminum cable bracket. Available with a single stud for throttle only or a double stud to add cruise control cable. Designed to work with part #491-1000LS1.

Lokar TCB-40LS14 2000-04 LS1 Throttle Cable Bracket, Double
                        Clean up your LS1 intake manifold with this billet aluminum cable bracket. Available with a single stud for throttle only or a double stud to add cruise control cable. Designed to work with part #491-1000LS1.

Speedway GM Engine Wiring Harness, 1999-02 LS1


Take the fear out of electronic fuel injection! These engine wiring harnesses are designed to make your engine transplant effortless. Each new harness contains in-depth application-specific instruction sheets, clearly marked factory GM connectors, labeled GXL jacketed wire, GM color coding, and pre-fitted corrugated slit loom for an extra value and professional look. All un-needed emissions wiring is eliminated to make the install as simple and reliable as possible. Standard length harnesses are 54" from the back of the engine to the PCM connectors.

1999-2002 LS1

  • Made from premium grade GXL jacketed automotive wire
  • Most wiring is larger gauge than stock application for durability
  • No splices to reduce points of failure
  • All primary grounding is done at the head or block and grounding points are isolated from each other to reduce electrical interference and minimize ground looping
  • Harness wiring matches GM wiring configuration and jacket colors follow GM color coding for easy identification
  • All electrical connectors are made by Delphi or Packard and are direct fit for GM cars and trucks
  • Can be installed to run engine in 20 minutes, but figure 4-6 hours for a professional installation
  • Diagnostic connector or OBD2 port for connection to scanners and tuning tools
  • Made in the USA.
Lokar TC-1000LS148 Universal LS1 / 350 Ramjet Throttle Cable, 48 Inch
                        You will need the correct throttle cable for your LS1 / 350 Ramjet engine swap. This cut-to-fit cable looks good and gets the job done.

Tru-Ram LS1 Exhaust Manifolds, Unpolished
                        Tru-Ram® Exhaust Manifolds allow you to enjoy the look of factory LS style manifolds, without the hassle of dealing with unsightly rust and corrosion. Investment cast from durable stainless steel material, these exhaust manifolds will be a low maitenance, high-performance addition to any LS-powered vehicle. Features an as-cast, unpolished finish for a distinctive look.
  • Tucked-in shape hugs block contour
  • Smooth internal transitions perform like shorty headers
  • Collector angle is optimized for maximum frame rail clearance on any application
  • Round 1-3/4" primary tubes
  • Large 3" collector outlet
  • Standard 3 bolt collector pattern
  • Includes stainless mounting hardware and gaskets
Hooker Headers 12622HKR LS Swap Engine Mount Adapter, 3 Inch Forward


Hooker LS engine swap mounts are designed to make the task of swapping an LS engine into your classic muscle car or truck as easy as possible. With five different mount kits available, you are sure to find the mounts needed to position the engine and transmission assembly in the appropriate location. Plates are available for use with stock small–block Chevy engine mounts to place the engine and transmission in the stock location or move it forward up to 3", depending on the mount.

  • Constructed of sturdy 3/8” thick hot rolled steel
  • Designed for lightweight, rigidity and a clean appearance
  • Precision machined for perfect alignment
  • Zinc plated for durability and corrosion resistance
  • Come complete with counter sink machine screws and instructions
  • Work with all small-block Chevy mounts and frame towers
  • Perfect for use with Hooker’s growing family of Gen III/IV (LS1/LS2/LS6/LS7) engine swap header

916-18018 Instructions (PDF)

Holley 302-1 LS Series Retro-fit Oil Pan


GM's popular LS engines are finding their way into a large variety of vehicles. They make great power, plus they're very durable and reliable. Unfortunately, the factory LS pans don't always fit or they hang too low for today's hot rods. Holley's new LS Retro–fit Engine Oil Pan is designed to help! It provides maximum clearance to the chassis and ground, plus provides an OEM fitment for durability and proper sealing.

  • Provides OEM fitment– OEM oil filter mounting, OEM oil cooler port provision, OEM engine NVH suppression, OEM flange gasket and sealing, proper structural rigidity and OEM bell-housing attachments
  • Traditional high-quality cast aluminum appearance with clean exterior styling
  • Provides maximum clearance to chassis
  • Cast and machined aluminum
  • Complete kit including sump baffle, pick-up tube, sump plug & oil filter stud
  • Fits GM rear wheel drive applications that were originally equipped with a Small Block or Big Block Chevy engine and traditional rear sump oil pan*

Holley Oil Pan Installation Instructions (PDF)

Specs Chart (GIF)

Lokar XTCB-40LS1 Black LS1 Throttle Bracket, 1998-99 GM, Single Stud


This billet aluminum bracket mounts to the side of the LS1 manifold and is comes with a single stud for throttle only.

Lokar XED-5008 1997-Up LS1 Midnight Series Flexible Engine Dipsticks
                        Flexible Engine Dipstick designed with billet aluminum handle to   coordinate with Lokar's Flexible Transmission Dipstick.  Slim design   allows mounting inside headers.  Designed for use with factory,   Sanderson cast manifolds or block hugger headers.   E-Z read flexible  inner dipstick measuring cable for accurate measure of engine oil.

Lokar TCP-1000LS1 36 In Polished LS1/350 Ramjet Hi-Tech Throttle Cable


Looking for more shine in your engine compartment? Try Lokar's Polished Hi-Tech Throttle Cables. Lokar's polished cables are available in stainless steel braided housing or black housing. They are designed with a specially extruded liner for extended life of the cable – not to be confused with ordinary braided brake hose. Cables are equipped with polished aluminum fittings and polished aluminum ferrule to eliminate fraying. "U-Cut-to-Fit" outer housing is available in 36" lengths with a "U-Cut-to-Fit" stainless inner wire. Clevis is designed without cotter pins or set screws. Adapts to factory and aftermarket pedals. Cables mount nicely with Lokar's array of bracket and return springs (sold separately). Kits complete with installation instructions. Pair up with a polished kickdown.

  • 36" long
  • GM LS1/Ramjet applications
  • Specially extruded liner for extended life of the cable
  • Aluminum fittings with ferrule to eliminate frayed cable ends
  • Adaptable for all types of manifolds including tunnel ram, blower manifolds and Weber induction systems
  • Complete instructions included

Throttle Body and Carb End Fittings Guide (Link)

491-001000 Instructions (PDF)

Lokar ED-5019 GM LS Flexible Engine Dipstick, 1999-Up Trucks
                        Flexible Engine Dipstick designed with billet aluminum handle to   coordinate with Lokar's Flexible Transmission Dipstick.  Slim design   allows mounting inside headers.  Designed for use with factory,   Sanderson cast manifolds or block hugger headers.  E-Z read flexible  inner dipstick  measuring cable for accurate measure of engine oil.

Lokar TC-1000LS160 Hi-Tech LS1 / 350 Ramjet Throttle Cable, 60 Inch
                        Lokar Hi-Tech Throttle Cable features a stainless   steel braided  housing.  They are designed with a specially extruded liner for extended    life of the cable – not to be confused with ordinary braided brake    hose.  Cables are equipped with aluminum fittings and aluminum ferrules    to eliminate fraying.
Kits come complete with installation instructions.
Book/Manual - How To Swap GM LS-Series Engines Into Almost Anything
                        How to Swap GM LS-Series Engines into Almost  Anything shows how to fit these powerhouse engines into popular GM  F-Body cars, such as the Camaro and Firebird, and also how to install  these powerplants into non-GM muscle cars, sports cars, trucks, and of  course, hot rods. This book includes a historical review, complete  specs, and detailed information so you can select and fit the best LS  engine for a particular vehicle and application.

A section on mounting kits, explaining how to install these engines into a variety of cars using readily available motor mount kits, universal engine mounts, or fabricated mounts. In addition, the book shows you how to perform necessary oil-pan modifications and adapt accessory drivers as well as choose the most suitable fuel pump, exhaust system, wiring harness, and electronic control module. This guide takes it a step further, revealing how to select the best reprogramming equipment and software for a vehicle and its application. Finally, the book covers the range of compatible transmissions for LS engines.
  • By Jefferson Bryant
  • 144 pages
  • Photos: 375 color
  • Paperback
  • Sold individually
Book/Manual - How to Rebuild GM LS-Series Engines
                        With the increasing popularity of GM's LS-series  engine family, many enthusiasts are ready to rebuild. How to Rebuild GM  LS-Series Engines is the first book of its kind to help you rebuild your  GM LS-series engine. It explains variations between the LS-series  engines and elaborates on the design features that make up this engine  family.

In this Workbench book, author Chris Werner uses more than 600 photos, charts, and illustrations to give simple step-by-step instructions on disassembly, cleaning, machining tips, pre-assembly fitting, and final assembly. This book gives considerations for both stock and performance rebuilds. It guides you through both the easy and tricky procedures, showing you how to rebuild your engine and ensure it is working perfectly. The book also illustrates many of the performance components, accessories, and upgrades that have been developed for the LS-series family of engines.

As with all Workbench titles, this book details and highlights special components, tools, chemicals, and other accessories needed to get the job done right, the first time. Appendices are packed full of valuable reference information, and the book includes a Work-Along Sheet to help you record vital statistics and measurements along the way. You'll even find tips that will help you save money without compromising top-notch results.
  • By Chris Werner
  • 152 pages
  • Photos: 604 color
  • Paperback
  • Sold individually
