Auto Meter 1402 Designer Black 5 Piece Gauge Kit

Specs
Sold in Quantity:
Kit
Gauge Type:
Electric
Lighted:
Yes
Depth:
2.67
Bezel Finish:
Black Chrome
Liquid Filled:
No
Gauge Face:
Black
MFG. Part #:
1402
Lettering Color:
White
Needle Color:
Fluorescent Red
Speedometer Diameter:
3.12
Auxiliary Gauge Diameter:
2.04
Garage Sale:
No
Gauge Range:
120 MPH/100 PSI/100-250 °F/8-18V/240OE-33OF
Light Color:
White Incandescent
Sending Unit:
Y
Lighting Type:
Incandescent
Includes Mounting Bracket(s):
Yes
Includes Bulb and Socket:
Yes
Includes Light Covers :
Yes
Bezel Style:
Street Rod
Included Adapter/Fitting:
1/8" NPT Male to 1/8" compression fitting, 1/8" NPT Female to 1/8" compression fitting, 1/8" NPT to 1/4" NPT bushing, 3/8" NPT and 1/2" NPT adapter fittings.
Notes
Includes all sending units. Oil pressure, Water temperature, Fuel level, Voltmeter, and Speedometer.
Auto Meter 1402 Designer Black 5 Piece Gauge Kit
Auto Meter 1402 Designer Black 5 Piece Gauge Kit
Product Video
Auto Meter 1402 Designer Black 5 Piece Gauge Kit

Click image to enlarge

Watch the video below for instructions on how to properly calibrate your Auto Meter Electric Speedometer.

Please NOTE the following about this product:

  • This item is sold as a set.

Details

Reviews

Q & A

What's in the Box

When you’re ready to install instrumentation in your high-performance vehicle, don’t settle for slow and inaccurate factory equipment. Auto Meters Designer Black Series Gauge Kit features their famous high performance movements and is designed for a seamless dashboard mount for the ultimate driver information center.

  • Advanced 90 degree air core movements
  • Simple three wire installation (per guage)
  • Programmable speedometer can compensate for tire size and gear ratio at the push of a button
  • Electric sending units keep hazardous fluids in the engine compartment
  • Sends collected data via an electrical signal to quick reacting, precise air core movements
  • Gives you all the information that you need and nothing that you don’t

Gauge set includes all senders. (See Application tab)

Application

Gauge kit includes a speedo sending unit that fits GM and Chrysler transmissions. If you are using a Ford transmission (1957-Newer), purchase our Ford-style sending unit 182-5292.

Notes

  1. Gauges illuminate via incandescent bulbs and around-the-dial lighting.
  2. Red and green bulb covers are included for a custom look.
  3. All Designer Black series gauges come with a domed lens.

Specs

  • Electric Speedometer housing is 3-1/8" O.D.
  • Speedometer bezel is 3.293" O.D.
  • Smaller gauge housings have 2-1/16" O.D.
  • Smaller gauge bezels have 2-3/16" O.D.

Item Details

with Black Bezel

Customer Reviews

Rated 5 out of 5 by 1 reviewers.
RATING BREAKDOWN
1 reviews
5 Stars
1
4 Stars
0
3 Stars
0
2 Stars
0
1 Star
0
RECOMMEND THIS PRODUCT:

wutnxt
Verified Purchaser
oregon
Product Rating

Cool gauges

November 15, 2010
I like the black chrome bezels and the domed lenses. The installation was simple with the speedway basic wiring harness and all supplied senders
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Page 1 of 1

Product Q&A

1 questions : 1 answers

What ohms does the fuel gauge run on?

1 answers
Corey
SC
November 17, 2011

What ohms does the fuel gauge run on?

Answers

November 18, 2011
Jason
240 ohm Empty 33 ohm Full
Page 1 of 1
