Aeromotive 11209 High Output Billet Electric Fuel Pump, 7 PSI

Free Shipping Free Shipping
Specs
GTIN Code:
684980002324
Aeromotive 11209 High Output Billet Electric Fuel Pump, 7 PSI

Click image to enlarge

Details

Reviews (1)

Q & A (3)

What's in the Box

Info

This is the new standard in 12-volt electric fuel pumps. This pump boasts a high-quality billet aluminum body and pumping mechanism that feature Aeromotive's proprietary composite rotors, stainless steel vanes and precious-ground, heat-treated steel plates. The black pump has a flow volume exceeding 90 GPH and is internally regulated to 7 psi, making it ideal for carbureted street applications up to 600 horse power. Has a polished body that look great on any street rod or race car.

  • Durable billet construction
  • Fuel flow exceeds 90 GPH at 5 PSI and draws less than 5 amps.
  • Internally regulated to 7 PSI
  • Eliminates the need for a separate regulator on most carburetors
  • Rated for continuous duty
  • Pumping mechanism features a composite rotor, stainless steel vanes and heat treated steel top and bottom plates for durability
  • 3/8” NPT inlet and outlet ports

Customer Reviews

Rated 5 out of 5 by 1 reviewers.
RATING BREAKDOWN
1 reviews
5 Stars
1
4 Stars
0
3 Stars
0
2 Stars
0
1 Star
0
RECOMMEND THIS PRODUCT:

Don
Verified Purchaser
Verified Reviewer
Texas

Aeromotive Fuel Pump

January 13, 2016
Would buy again.
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Page 1 of 1

Product Q&A

3 questions : 3 answers

1 answers

does it have internal relief valve or does it require a return line

redride
North Carolina, USA
August 02, 2013

does it have internal relief valve or does it require a return line

Answers

August 05, 2013
Jason
This Aeromotive electric fuel pump does not require a return line to tank. This pump is internally regulated to 7 PSI, eliminating the need for a separate regulator on most carburetors.
1 answers

Is it Methanol compatable

Graeme
June 08, 2013

Is it Methanol compatable

Answers

June 10, 2013
Jason
Yes, part #91011209 is methanol compatible along with pump part #91011203.
1 answers

is bracket included .would this need gravity flow canit be mounted above lvel of gas tank

camaro
May 30, 2013

is bracket included .would this need gravity flow canit be mounted above lvel of gas tank

Answers

May 30, 2013
Jason
The Aeromotive 11209 electric fuel pump does include a mounting bracket. The pump should be mounted lower than and as close as possible to the fuel tank.
Page 1 of 1
