AFCO Non-Adjustable Alum. Coil-Over Shock Kit, 4 Inch Stroke, 10 Inch Comp.

Free Shipping Free Shipping
Specs
Material Type:
Steel
Sold in Quantity:
Kit
Finish:
Powder Coated
Shock Body Material:
Aluminum
Upper Shock Mount:
5/8 Bushing
Lower Shock Mount:
5/8 Bushing
Inside Diameter:
2.625
Extended Length:
14.25
Compressed Length:
10.32
Mounted Length:
11.50
Spring Rate:
-
AFCO Non-Adjustable Alum. Coil-Over Shock Kit, 4 Inch Stroke, 10 Inch Comp.

Click image to enlarge

Details

Reviews (0)

Q & A (3)

What's in the Box

Info

AFCO has been building racing shocks for over 20 years and are now applying their technology to street rod shocks. These aluminum coilover shock kits have superior FIXED valving that will give you a better ride and improve handling.

  • 4 Inch Stroke
  • 10 Inch Compression
  • 14 Inch Extension
  • Each shock is hand built and dyno tested
  • Supplied with two 5/8" I.D. polyurethane bushings
  • Includes AFCO Mirror Finish coilover springs in the rate of your choice
  • Kit includes (2) shocks, (2) springs, and (2) coil-over hardware kits

Warranties

Afcoil springs are manufactured using the finest spring material available. They are designed for extended life and consistent performance. They are guaranteed to do the job for which they are designed for as long as they are owned by the original purchaser.

AFCO will replace any Afcoil spring that ever exceeds the maximum allowable 2% loss of free height from original nominal specification. One way freight is included.

  1. Guarantee applies to original retail purchaser only.
  2. Damaged springs not covered by warranty.
  3. Spring must be returned to AFCO freight prepaid along with a copy of the original invoice.
  4. No other warranty, either expressed or implied, applies to Afcoil springs.
(Warranty not valid without invoice.)

Customer Reviews

This product has no reviews.

Product Q&A

3 questions : 3 answers

1 answers

Will this shock allow for a spherical bearing to be used? Looking at the AFCO coil-over shock kit, Non-adjustable unit ... can the bushing shown in the picture be changed to a bearing? Also, can you tell me what part number shock this is? Thanks

JimDiesel
Indiana
March 09, 2014

Will this shock allow for a spherical bearing to be used? Looking at the AFCO coil-over shock kit, Non-adjustable unit ... can the bushing shown in the picture be changed to a bearing? Also, can you tell me what part number shock this is? Thanks

Answers

March 10, 2014
EricM
Yes you can use any of these spherical bearings: 1061000 - 1/2" bolt size, 5/8" wide 1061007X - 1/2" bolt size, 1 1/16" wide 1080 - 5/8" bolt size, 1/2" wide
1 answers

What is the greatest outside diameter (including the spring) of this shock.

Steve
March 10, 2016

What is the greatest outside diameter (including the spring) of this shock.

Answers

March 11, 2016
Eric
Expert
This kit uses 2 5/8" ID springs. The springs will vary slightly in OD depending upon the spring rate (the stiffer the rate the larger the OD). The springs will be around 3 5/8" OD but a spring rate would need to be known to get an exact OD. The springs are the largest part of the coil over assembly.
1 answers

What millimeter is the mounting portion width of the shockabsorber? (both side upper and lower)

kan-chan
Tokyo Japan
July 09, 2016

What millimeter is the mounting portion width of the shockabsorber? (both side upper and lower)

Answers

July 12, 2016
John
Expert
The mount I.D. for the shock studs or supports is 5/8" or 15.875 mm. The width of the shock eye side to side is 1.5" or 38.10 mm.
Page 1 of 1
