Jim Osborn MP0109 70 Chevy II Nova Wiring Diagrams
Click image to enlarge
Q & A (0)
What's in the Box
- Reprint of the original wiring diagram manual
- Book covers the chassis, light and general wiring harness information for your car
- For 1970 Chevy Nova
- Camaros & Classics part number BK2283
