6-Volt Alternator for Wide 5/8 Inch Belt

SAME DAY SHIPPING! Order within the next 6 hours 13 minutes and receive same day shipping

Free Shipping Free Shipping
Specs
Sold in Quantity:
Each
Garage Sale:
No
Overall Length:
6.625
Belt Width:
.625
Base Width:
5.50
Amperage:
60
Voltage:
7.5
6-Volt Alternator for Wide 5/8 Inch Belt

Click image to enlarge

Details

Reviews

Q & A

What's in the Box

If you are still running the 6-volt system on your car, truck or even tractor, the generator is your weak point. Even at highway speed that old generator cannot put out enough to keep up with the lights, heater motor and radio. This alternator puts out 60 amps at 7.5 volts at highway speeds, up to 30 amps at idle, and has the regulator built in. It includes the required plug and can be installed on almost any engine by modifying or purchasing a new mounting bracket.

Specs

  • 6-5/8" from the back to the front of the pulley hub
  • 6-1/2" mounting holes on center
  • 5-1/2" across

Customer Reviews

This product has no reviews.

Product Q&A

4 questions : 4 answers

1 answers

I have a positive groung system on my truck, what do I have to do to convert it to negative ground?

shelrl
Louisiana, USA
June 08, 2014

I have a positive groung system on my truck, what do I have to do to convert it to negative ground?

Answers

June 10, 2014
EricM
In changing from positive to negative ground first unhook the battery terminals. On the gauges you will need to take the ammeter or voltage gauge out and reverse the wires so when running the gauge will show positive. If you have any motors such as fan motor for the heater or engine the wires will need to be reinstalled in reverse. The wires to the coil need to be reversed also or you will only get about half of the voltage up to the distributor and have a weak spark. Finally rotate the battery 180 degrees and if the cable won’t reach you will have to lengthen the cables or install new. You now have negative ground.
1 answers

Can this alternator be used on a positive grd 6v system?

January 26, 2011

Can this alternator be used on a positive grd 6v system?

Answers

January 28, 2011
Jeremy O
Hello, FYI:This 6 volt alternator will require that the car/truck have 'negative' ground. If the car/truck is currently 'positive' ground, the polarity will need to be reversed.
1 answers

Hello! What are the dimensions of the alternator?

Nebo
Toronto, ON
April 16, 2011

Hello! What are the dimensions of the alternator?

Answers

April 19, 2011
Seth
This alternator is 6-5/8" from the back to the front of the pulley hub, 6-1/2" mounting holes on center and 5-1/2" across.
1 answers

Which bracket should i use to mount this 6v alternator to my 1953 flathead in place.of generator bracket. thanks

cadatak
western australia
June 04, 2015

Which bracket should i use to mount this 6v alternator to my 1953 flathead in place.of generator bracket. thanks

Answers

June 05, 2015
Eric
Expert
Bracket part number 91667910 will mount this alternator onto your 1953 Flathead engine.
