1949-1954 Early Chevy Car Straight Axle

Specs
Material Type:
Steel
Sold in Quantity:
Each
Finish:
Natural
Diameter:
2.00
Drop:
0
Material Thickness:
.250
Garage Sale:
No
King Pin Centers:
-
Spindle Type:
Chevy
King Pin Boss Length:
2.13
Overall Length:
-
King Pin Diameter:
.87
Notes
With flat plate steering arms this part will use a tie rod link on 45.50" eye-to-eye.
1949-1954 Early Chevy Car Straight Axle1949-1954 Early Chevy Car Straight Axle
1949-1954 Early Chevy Car Straight Axle

Click image to enlarge

Watch the video below to learn more about Speedway Motors Spindles

Speeday Motors Logo
X
1949-1954 Early Chevy Car Straight Axle

Details

Reviews

Q & A

What's in the Box

Our plain steel tube axles are universal-fit, and professionally engineered & built. Features welded ends which require 1949-54 Chevy passenger car style spindles. Choose from 44"-50" widths (kingpin center-to-center), or order a custom length to fit your needs.

  • Axle Tube:  0.250" wall
  • Axle Diameter: 2.00" O.D.


Gasser Build Info (PDF)

Item Details

For custom width axle, specify length in comments section of shopping cart at checkout.

You may also be interested in:

Chevy Front Axle Steering & Brake Kit, 48 Inch Axle


Speedway's exclusive steering & brake kits save you time and money by combining all necessary parts into one part number. Each kit includes brake kit, spindles, dust caps, spindle nuts, AN3 caliper fittings, Rubber Brake Lines, kingpins, flat steering arms, tie rod assembly and hardware.

For 48" kingpin-to-kingpin axles. Traditional steering arm for left front wheel NOT included with Traditional steering kit.

  • Speedway 1949-1954 Chevy Spindles
    • One piece forged 4140 steel
    • Modeled after the 49-54 Chevy passenger car spindles
    • Steering arms may be mounted to the top or bottom of the spindle
    • Standard king pins fit to spindles
  • Speedway 9-1/4" Brake Kit
    • 9-1/4" Mustang II rotors
    • 5 x 4-1/2" or 5 x 4-3/4" bolt patterns
    • Wheel studs - 1/2" Fine (4-1/2" BP), 7/16" Fine (4-3/4" BP)
    • Hub flange (hat) diameter - 5.74"
    • GM Metric '78-'88 calipers, 2-1/2" piston
    • 7/16" banjo bolt to -3 AN line adapter kit
  • Traditional or Cross Steering Kit
    • Flat plate steering arms
    • 5/8" tie rod steering link
    • 5/8" standard heim joint rod ends
    • Seals-It 5/8" rod end seals
    • 5/8" steel cone heim spacers

Spindle Identification Guide (GIF)

Dropped Semi-Elliptical Gasser Axle Kit, Chevy Spindle, 4 Inch Drop


Black steel, universal application, professionally engineered. Spring pads to be welded to the axle by the builder and are therefore adjustable on the axle for different frame widths. For 1949-54 Chevy style spindles.

Gasser Build Info (PDF)

Kit includes:

  • 48" double bend tube axle w/ welded ends (0.250" wall tubing)
  • two axle pads and U-bolts
  • two 1-3/4" spring shackles w/ nylon bushings
  • two frame mounting brackets
  • two 32" 6-leaf springs
  • all hardware

916-3903 Instructions (PDF)

Semi-Elliptical Straight Axle Kit for Chevy Spindle


If you are looking for that "up in the front" gasser look or just need a straight axle, we've got your deal! We can supply you a complete semi-elliptical straight axle front end kit with springs and hardware. Designed for use with Speedway 1949-54 Chevy-style passenger car spindles.

Gasser Build Info (PDF)

Plain steel, universal application, professionally engineered. The spring pads are adjustable on the axle for different frame widths (welding required). Choose axle length from kingpin to kingpin, or order a custom length.

Kit includes:

  • tube axle w/ welded ends (0.250" wall tubing)
  • two axle pads and U-bolts
  • two 1-3/4" spring shackles w/ nylon bushings
  • two frame mounting brackets
  • two 32" six-leaf springs
  • all hardware
916-3903 Instructions (PDF)
